Foot Related Injuries & Treatments

Ankle Stretching, Rehabilitation & Taping

Stretching

stretch1

Stretching the Calf (not the actual Achilles Tendon)

Done barefoot (without bouncing) with toes pointed straight ahead, weight on front foot not on the back leg.

Hold for 15 seconds

stretch2

**WARNING: Do NOT do this stretch if you have Achilles Tendon problems.**

Stretching of the calf AND Achilles Tendon can be done by balancing on one foot, then standing on your toes, ideally one legged.

Try to start with 3 sets of ten repetitions--progress to 5 sets of 25 reps.

stretch2

Balance Exercises

balance1

Balance Strengthening Exercise:

Try to balance for 15 seconds on one foot on a pillow or piece of foam, ideally barefoot.

balance2

Advanced Balance Strengthening Exercise:

While balancing wave a ball or weight. You can also bounce a ball against a wall while balancing.

balance2

Eccentric Strengthening

heel6

Up with two, down with one: start on flat surface, 3 x 10 reps
Eventually add stairs and weight as in Second Image.

Inversion and Eversion Exercises

inversion1

INVERSION Strengthening Exercise

Move the towel by moving your foot only (try not to use your hip, knee or lower leg) dragging the weighted end towards your foot.

Repeat 19 times

inversion2

EVERSION Strengthening Exercise

Move the towel by moving your foot only (don't use the motion from your knee or hip) dragging the weighted end towards your foot.

Repeat 19 times.

Fig9A
Fig9B

Ankle Taping Stages - Standard Method

tape1

Start with Elastic Tape from the medial aspect of the leg while keeping the foot at a right angle to the leg. Pull the tape and attach to the outside of the ankle.

tape2

Next take either white athletic (Zonas) tape or pink Kinesio tape and do a "figure 8" around the foot starting with the outside of the ankle, go under the arch medially, pulling the foot laterally. This helps take tension off of the outer (lateral) ligaments.

tape3

Next take either white athletic (Zonas) tape or pink Kinesio tape and do a "figure 8" around the foot starting with the outside of the ankle, go under the arch medially, pulling the foot laterally. This helps take tension off of the outer (lateral) ligaments.

tape4

To add more support use white Zonas tape to create a medial to lateral "stirrup".

tape4

For even more support add a "heel lock" to pull the heel in eversion, again pulling the foot laterally.

tape6

For even more support add a "heel lock" to pull the heel in eversion, again pulling the foot laterally.

tape7

You can anchor the tape straps by putting circumferential straps around the ankle

Ankle Taping Stages - Kinesio Method

Kinesio tape is a "low-bulk" (& less supportive) tape job. This may be
better for less acute injuries, soccer players, dancers & runners.

kinesio-1

Start medially on the heel

kinesio-2

Finish laterally with the same strap.

kinesio-3

Start medially perpendicular to the 1st strap

kinesio-4

End laterally on the foot keeping the foot at neutral. You can repeat with more layers.
